Excavator E6375FEH
Field of application:
Utilities
Heavy infrastructure
Quarries & Aggregates
Features
Technical Parameter
| Total mass (kg) | 38200kg |
| Bucket capacity | 1.9mu00b3 |
| Bucket capacity range | nan |
| Average ground pressure | 70.1mm |
| Circumstance temperature | nan |
| Slewing speed | 10.3r/min |
| Traveling speed (low/high) | 3.7/5.0km/h |
| Maximum digging force | 234.4kN |
| Altitude | 4500m |
| Wading depth | 811mm |
| Engine model/Drive Motor Model | 6HK1X |
| Engine power | 212KW |
| Maximum flow rate | 2u00d7340+28.5L/min |
| Fuel specifications and filling amount | 620L |
| Overall length | 11335mm |
| Overall width | 3510mm |
| Overall height | 3840mm |
| Boom length | 6450mm |
| Wheel track | 2740 |
| Arm length | 2950mm |
| wheelbase | 4240mm |
| Crawler wheelbase/Wheelbase | 4240mm |
| Maximum digging radius | 10870mm |
| Maximum digging depth | 7345mm |
| Maximum discharge height | 7100mm |
| Overall length during transfer | 11335mm |
| Shovel width (with band edge) | 1680mm |
| Maximum digging depth under length of bottom surface of 2.5m | 7160mm |
| Maximum digging height | 10280mm |
| Contour dimension of complete machine (transfer position) | 11335u00d73510u00d73840mm |
| Overall width of upper assembly | 3415 |
| Overall width of chassis | 3340mm |
| Overall height to cab top | 3246mm |
| Rear slewing radius | 3570mm |
| Overall height to hood top | 2700mm |
| Ground clearance of upper assembly | 1204mm |
| Overall length of crawler | 5180mm |
| Wheel track of crawler/Wheel track | 2740mm |
| Track shoe width | 600mm |
| Minimum ground clearance | 530mm |
| Overall height of working mechanism during transfer | 3840mm |
| Maximum digging radius of reference ground | 10870mm |
| Maximum vertical digging depth | 4750mm |
| Minimum front turning radius | 4405mm |
