Operating weight | 55700KG |
Loading capacity | 55000KG |
Max. tractive force | 345KN |
Engine model | WP13G375E470 |
Rated power | 276KW |
Transmission type | VOLVO HTE220B |
Gears | F4 R4 |
Fuel tank | 580L |
Overall length | 10770mm |
Overall width | 3850mm |
Overall heigth | 3830mm |
Ground clearance | 420mm |
Wheel base | 4700mm |
Fork horizontal lifting high | 3600mm |
Max. lifting high | 4170mm |
