Operating weight | 3070KG |
Engine model | D1803-M-DI-ET05 |
Rated power | 24.4KW |
Drive type | Hydraulic drive |
Gears | Variable speeds |
Nominal amplitude (high/low) | 0.5mm |
Frequency(low/high) | 55/67HZ |
Excitation force (high/low) | 46/31KN |
Static linear load(high/low) | 120/131N/cm |
Fuel tank | 40L |
Overall length | 2424mm |
Overall width | 1337mm |
Overall heigth | 2831mm |
Width of vibratory drum(D/E) | 1200mm |
Wheelbase | nan |
Min.ground clearance | 260mm |
Theoretical gradeability | 0.3 |
